The intelligent oil analyzer is applied in the fields of rail transit such as railways and subways, as well as transportation equipment such as ships. It is widely used for the qualitative and quantitative analysis of worn metals, additive consumption, and pollutants in lubricating oils used in transmission and running parts. The uniqueness of this instrument lies in its superior analytical performance and simple operation, which can be operated by non professionals. Its important function is to be able to analyze the element content and the presence of wear elements and pollutants in lubricating grease within a few minutes, and the analysis work can be carried out in any place where oil is used. The intelligent oil analyzer is mainly used for analyzing sulfur elements, heavy metals, wear metals, elemental additives, pollutants, etc. in lubricating oil, grease, gasoline, jet fuel, kerosene, hydraulic oil, crude oil, residue, wax oil, alcohol gasoline, biodiesel, and other similar petroleum products.
Application field:
Military field
Aerospace field
Electricity industry
Transportation industry
Technical parameters:
Analysis of element range: all elements between magnesium (Mg) and uranium (U);
Test objects: solid, powder, liquid;
Content range: 2ppm-99.99%;
Analysis method: Energy dispersive X-ray fluorescence analysis method;
Detector: SDD/Fast SDD detector, with a minimum resolution of 130eV/125eV;
Working temperature: -10 ° C~+50 ° C;
Working humidity:<90%;
Detection limit: The detection limit of S element in fuel is 10ppm/2ppm;
Handling: One click testing, no need to select specific testing mode;
Detection time: 30-300 seconds;
Size: 400mm * 360mm * 300mm (length * width * height);
Weight: About 25 kg.
Features and advantages:
Using HAPG polarization target material effectively improves the sensitivity of light elements;
Easy to operate, automatic sampling, one click completion of multiple sample testing, and one minute quick detection make "oil change according to quality" possible;
High resolution and good repeatability make accurate measurement possible; We have conducted centralized calibration and analysis on the concentration points of railway oil products in use and the special elements that railway oil products are concerned about, and implanted the data and curves into the equipment, making it more closely related to on-site application;
Very cost-effective, analyzing multiple common elements makes "comprehensive analysis" possible;
Lubricating grease is directly placed into the oil box for testing, without the need for heating, dissolving or other steps on the grease, and without damaging the sample. The entire process is tested for no odor or harmful gases, and there is no need to place it in a fume hood, providing protection for the health of the test personnel;
A customized method package for elemental analysis of railway lubricating grease has been configured, which can directly analyze the quantitative analysis of worn metals and additive elements in the grease. It can analyze multiple elements such as Fe, Cu, Si, Zn, Ca, S, Cl in gearbox oil, diesel engine oil, hydraulic oil, axle box bearing grease, traction motor grease, etc., achieving more targeted detection, making detection more convenient and data more accurate;
Low consumables cost and low consumption.
