Environmental testing requirements: Meet the requirements of Group I of Climate Environmental Testing, Group I of Mechanical Environmental Testing in GB/T 14710-2009, and Table 3 of this technical requirement. The transportation test and power supply voltage adaptability test of the analyzer should comply with the requirements of Chapter 4 and Chapter 5 of GB/T 14710-2009, respectively.
Safety requirements: Meet the requirements of applicable clauses in GB 4793.1-2007, GB 4793.9-2013, and YY0648-2008.
Electromagnetic compatibility requirements: comply with the requirements of applicable clauses in GB/T18268.1-2010 and GB/T18268.26-2010.
The specific protein analyzer uses scattering turbidimetry to determine the reaction between antigens and antibodies, and the rate method is used during the measurement process. Compared to other measurement methods, this method has higher sensitivity and faster detection speed, and is not affected by background scattering signals. Specific protein analyzer is mainly used to measure the content and activity of specific protein molecules in biological samples such as serum and plasma, and the interaction between these protein molecules and other molecules (such as antibodies and ligands). It can be used to detect tumor markers, infectious diseases markers, cardiovascular disease markers, etc., and dynamically monitor the content and change trend of these markers, Improve early diagnosis of diseases and assess treatment outcomes. In addition, specific protein analyzers can also be used for drug screening and efficacy evaluation research.
Application field:
Hospital
Health center
laboratory
Animal Hospital
Instrument size: not greater than 150mm * 100mm * 70mm;
Analysis method: rate scattering turbidity method;
Optical system: Single wavelength semiconductor light source with a wavelength of 650nm, disposable organic glass colorimetric cup;
Reagent: Special reagents for analyzer matching;
Reaction site: 1 cuvette site;
Sampling method: manual sampling;
Data processing: storage and monitoring of test results, result query, result printing, with 4G or above networking and WIFI functions, capable of uploading and downloading information, remote upgrading and maintenance;
Measurement channel: 1 channel;
Temperature control and stirring: automatic temperature control and automatic stirring;
Testing steps: Used in conjunction with pre packaged reagents, the testing steps are simple and only require one step. The results are immediately available;
Operating software: Adopting real-time multitasking operating system, Chinese operating language, user-friendly interface and comprehensive data management, hierarchical menu control, simple operation;
Standard storage: can store 20000 sets of test data;
External device: Bluetooth printer.
Product performance:
Precision: Precision is expressed in coefficient of variation (CV), with a requirement of ≤ 5%;
Accuracy: Accuracy is expressed as the deviation (B) between the test average and the indicated value, with a requirement of ≤ ± 5%;
Instrument stability: The deviation (B) between the average value and the indicated value after 4 and 8 hours of startup is required to be ≤ ± 5%.
